Test Rig / Laboratory
Our modern testing facility / laboratory with numerous benches and the latest measurement technology enables industry-oriented and practice-oriented research and development:
- Model acceptance tests acc. to IEC 60193, IEC 62006, ISO 9906, IEC 60534,
- Duration test arrangements
- Plant, operating and life-cycle testing
- Comparisons of experimental data with numerical simulation (Computational fluid dynamics, 3D-CFD)
4-quadrant test according to IEC 60193
Available tests:
- Turbines
- Shut-off
- Pumps
- Valves
- Pump-turbines
- Pipe systems
Measurement technology:
- Laser Doppler anemometry (LDA)
- Particle image velocimetry (PIV)
- Cavitation
- Efficiency measurement
- Characteristic curve measurement
Parallel test rig for axial turbine seal
Parallel structure - on the test bench are always checked two units simultaneously.
Specifications of the test rig:
- Speed-controlled drive (15/30kW)
- Measurement of
- Friction torque for driving power
- Leak / leakage
- Pressure
- Continuierliche Record all measurements
- Dosed insertionof abrasives enables tests under extreme conditions
[More Infos / pics for parallel test rig for axial turbine seal...]
Test rig for shaft sealing of pumps
The test rig is adapted to customer requirements and enables accurate simulation of attrition of the mechanical seal under a specific or different operating conditions.
Specifications of the test rig:
- Max. Shaft diameter: 170 mm
- Speed: 5,700 rpm
- Pressure side: P = 40 bar
- Test rig for long-term test with continuous data recording
- Remote monitoring
- Deionized water (DI water)
- Conductance: 0.1 ĩS / m
- Automatic water treatment
- Temperature 60 ° C
[More infos / pics for Test rig for shaft sealing of pumps...]
Test rig for water hammer
Test rig for simulation of transient processes. For optical observation of cavitation the test rig consists of five Plexiglas tube segments.
Specifications of the test rig for water hammer:
- 300 m loop
- 2 "diameter tubing
- Plexiplas pressure vessel
- 3400 liter tank
Air test rig
Available test for:
- Turbines
- Pumps
- Valves / fittings
- Pipe systems
Measurement equipment:
- Laser Doppler anemometry (LDA)
- Hot-wire anemometer
- Efficiency measurement
- Characteristic curve measurement
- 5-hole sensor, adjustable during operation
More information / figures:
- 4-Quadranten test rig acc. to IEC 60193
- Parallel test rig for axial turbine seal
- Test rig for shaft sealing of pumps
- Acceptance / Approval test acc. to IEC 60193
Requests
tugraz.at
References test rig
Publications and additional information
Standards & norms
- IEC 60193: Hydraulic turbines, storage pumps and pump-turbines – Model acceptance tests
- IEC 60534: Industrial-process control valves
- ISO 9906: Rotodynamic pumps – Hydraulic performance acceptance tests
- IEC 60041: Field acceptance tests to determine the hydraulic performance of hydraulic turbines, storage pumps and pump-turbines
- IEC 62006: Hydraulic machines – Acceptance tests of small hydroelectric installations
The list above is an excerpt. For the fulfillment of other standards please contact us.
